| Overall Specifications | |
| N.W. | 915g |
| Product meas. | 134.5*118*193.8mm |
| Input voltage | 14.8V~25.2V |
| Dynamic current | 750~1250mA @ 16V |
| Power consumption | Average 12W, Max 20W |
| Working environment temp. | -20℃ ~ +50℃ |
| IP rate | IP4X |
| Output (optional) | micro HDMI(1080P 60fps) / IP (RTSP/UDP 720p/1080p 30fps H264/H265) |
| Storage | TF card (Up to 256G,class 10, FAT32) |
| Picture in TF Card | JPG(1920*1080) |
| Video in TF Card | MP4(1080P@30fps) |
| Control method | PWM / S.BUS / UART (TTL) / TCP / UDP |
| Gimbal Spec | |
| Mechanical Range | Pitch/Tilt:-60°(Up)～125°(Down), Roll: ±40°, Yaw/Pan: ±300° / ±360°*N (IP output version) |
| Controllable Range | Pitch/Tilt: -45°～120°, Yaw/Pan: ±290° / ±360°*N (IP output version) |
| Vibration angle | Pitch/Roll/Yaw: ±0.02° |
| One-key to center | √ |
| EO Camera 1 spec | |
| Imager Sensor | 1/2.8" Sony CMOS Sensor |
| Picture quality | Full HD 1080 (1920*1080) |
| Effective pixel | 2.13MP |
| Lens optical zoom | 40x, F=4.25~170mm |
| Digital zoom | x32 |
| Field of View (D, H, V) | Wide: 73.80° / 66.35° / 39.98° |
| Tele: 2.16° / 1.90° / 1.11° | |
| Min object distance | 0.1 / 1.5 / 3.0 / 5.0 / 10.0 m |
| Min illumination | Color(1/30s, 79.5dB) : 0.01 lux , BW(1/30s, 79.5dB) : 0.002 lux |
| Color DSS(1/1s, 79.5dB) : 0.001 lux , BW DSS(1/1s, 79.5dB) : 0.0002 lux | |
| S/N ratio | more than 50dB |
| Focus | Auto / One Push / Manual |
| White balance | Auto |
| Shutter speed | 1/1 ~ 1/30,000 sec |
| Exposure control | Auto / Iris. Priority / Shut. Priority / Manual |
| Backlight compensation | Yes |
| Auto ICR | Yes |
| Image Stabilizer | Yes |
| Defog | Yes |
| EO Camera 2 Spec | |
| Imager Sensor | 1/2.9" CMOS Sensor |
| Image pixel | 2MP |
| Picture quality | Full HD 1080 (1920*1080) |
| Focus Length | 6mm |
| Digital zoom | 1x~12x |
| Field of View | FOV：D 60° H 50° V 28° |
| Camera Object Tracking | |
| Update rate of deviation pixel | 30Hz |
| Output delay of deviation pixel | <30ms |
| Minimum object contrast | 5% |
| SNR | 4 |
| Minimum object size | 16*16 pixel |
| Maximum object size | 256*256 pixel |
| Tracking speed | ±48 pixel/frame |
| Object memory time | 100 frames |
| Camera AI Performance | |
| Targets type | Car and human |
| Simultaneous detection quantity | ≥ 10 targets |
| Min contrast ratio | 5% |
| Min target size | 5×5 pixel |
| Car detection rate | ≥85% |
| False alarm rate | ≤10% |
