Введение в продукт
Спецификация
TC-30 LTE-Based HD Data & Video Transmission System Specification
| Definition | Parameter |
| Transmission Distance | 30 km Air-to-Ground (LOS) |
| Operating Frequency Band | 1.4 GHz |
| Transmission Latency | Data ≤20 ms; Video ≤200 ms |
| RF Channel | Supports 1T2R (1 Transmit, 2 Receive) |
| Receiver Sensitivity (Access) | 10 MHz: -103 dBm; 5 MHz: -106 dBm |
| Channel Bandwidth | 1.25 / 2.5 / 5 / 10 / 20 MHz |
| Modulation Mode | BPSK / QPSK / 16QAM / 64QAM |
| Power Control | Dynamic Power Control |
| Operating Voltage | Recommended 24 V (Max 36 V) |
| Peak Power Consumption | 18 W |
| Interface Type | Ethernet ×1 / TTL ×1 |
| Data Throughput | Max 30 Mbps uplink & downlink @20 MHz |
| Networking Mode | Point-to-Point; Star Network, up to 1+16 nodes |
| Startup Time | ≤30 ms |
| Configuration Tool | WEB UI Supported |
| Communication Encryption | Hardware ZUC / SNOW3G / AES supported |
| Transmission Mode | Unicast / Multicast / Broadcast |
| Frequency Hopping | Adaptive Frequency Hopping |
| Max Current | 0.75 A |
| Temperature Range | Operating: -20°C ~ +55°C; Storage: -40°C ~ +85°C |
For more details, please visit TC-30 LTE-Based HD Data & Video Transmission System 30KM Transmisson Distance
-
