Product Introduction
Specification
T-motor U8Ⅱ PRO KV100 Power Efficiency Multirotor Specification
| Motor Size | Φ87.3*29.55mm | Lead Cable | 90mm |
| Stator | Anti-rust treatment; | Copper Wire | 220℃ high temperature resistance |
| 180℃ high temperature-resisting coatings | |||
| Configuration | 36N42P | Coil Insulation Test | 1000V/5s |
| Shaft Diameter | IN：12mm | Rotor Dynamic Balance | ≤15Mg |
| Standard | |||
| Bearing | Imported 6901ZZ | IP | IP56 |
| Magnet Level | 180℃ high temperature resistance | Packing Size | 130*111*50.6mm |
| KV | 100 | Rated Voltage(Lipo) | 12S(4.2V/pc) / 48-52V |
| Idle Current(24V) | 1.0A | Internal Resistance | 134-141mΩ |
| Peak Current(180s) | 31A | Weight (Incl. Cable) | 287g |
| Max. Power(180s) | 1450W | Package Weight | 454g |
For more details, please visit T-motor U8Ⅱ PRO KV100 Power Efficiency Multirotor
-
